Teltonika TRB255 - Passerelle LTE - 4G - Alimentation CC

<a href="https://teltonika-networks.com/product/trb255/#features" style="display: block;">https://teltonika-networks.com/product/trb255/#features</a><br><br>TRB255 is an industrial Gateway equipped with a number of Input/Output, Serial, Ethernet ports and LPWAN modem. With backwards compatibility to EGPRS (2G) network, legacy industrial devices can be upgraded for extended use and support of LTE Cat M1 and NB-IoT ensures long lifecycle. Number of all features makes this Gateway perfect in application where legacy and modern industrial equipment must be integrated in one system.<br><br>

Teltonika TRB255000000. Management protocols: SNMP, Supported network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, PPP (planned),... Authentication method: Pre-shared key, digital certificates, X.509 certificates. Ethernet LAN data rates: 10,100 Mbit/s, Networking standards: IEEE 802.3, IEEE 802.3u. Serial interface type: RS-232/485. Width: 83 mm, Depth: 25 mm, Height: 74 mm

TRB255 can be used to integrate modern and legacy industrial equipment into one solution via RS232, RS485, and Ethernet interfaces. This industrial LTE Cat M1 and NB-IoT gateway is backward compatible to EGPRS (2G) networks. It can still be used with 2G network, however in case it gets shut down, there is a possibility to switch to LPWAN connectivity options.
TRB255 has a wide range of industrial and networking features such as Modbus, SMS control, Firewall , OpenVPN and more. This product is compatible with the Teltonika Networks Remote Management System (RMS).

• Connectivity - 4G/LTE (Cat M1), NB-IoT, 2G
• Dual SIM - with auto failover, backup WAN, and other switching scenarios
• Serial ports - RS232/RS485 serial communication interfaces
• 9-30V - wide range of supported power supply voltages
< li>I/O - multiple inputs and outputs for remote monitoring and control
• GNSS - Global Navigation Satellite System for location services with geofencing functionality

General

Management protocols

SNMP

Supported network protocols

TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, PPP (planned), UPNP (planned), SSH, DHCP, Telnet, MQTT (planned), Wake On Lan (WOL) (planned)

Authentication method

Pre-shared key, digital certificates, X.509 certificates

Ethernet LAN data rates

10,100 Mbit/s

Networking standards

IEEE 802.3,IEEE 802.3u

Serial interface type

RS-232/485

Width

83 mm

Depth

25 mm

Height

74 mm
