General
Device Type
Wireless router - 4-port switch (integrated)
Enclosure Type
Desktop
Connectivity Technology
Wireless, wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
Frequency Band
2.4 GHz / 5 GHz
Data Transfer Rate
1733 Mbps
Capacity
Guest networks: up to 6
Network / Transport Protocol
PPTP, L2TP, PPPoE, DHCP
Routing Protocol
Static IP routing
Encryption Algorithm
WPA, WPA2
Features
Print server, IPv6 support, parental control, Wi-Fi Protected Setup (WPS), reset button, IPv4 support, 4T4R MIMO technology, MU-MIMO technology
Compliant Standards
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
RAM
512 MB
Flash Memory
256 MB
Expansion / Connectivity
Interfaces
WAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ LAN: 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ USB 3.0: 2 x 9 pin USB Type A
Aerial
Aerial
Internal
Antenna Qty
8
Power
Power Device
External power adapter
Voltage Required
AC 120/230 V (50/60 Hz)
Dimensions & Weight
Width
26.65 cm
Depth
18.4 cm
Height
8.2 cm
Weight
620 g
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
