<a href="https://www.aten.com/global/en/products/professional-audiovideo/video-extenders/ve3912t/" style="display: block;">https://www.aten.com/global/en/products/professional-audiovideo/video-extenders/ve3912t/</a><br><br>The ATEN VE3912T is an HDBaseT transmitter that extends 4K DisplayPort, HDMI, or VGA video signals up to 100 m over a single Cat 6/6a or ATEN 2L-2910 Cat 6 cable. Featuring multiple video input formats and output resolutions up to 4K, it ensures a superior video quality for applications that require digital/analog sources conversion and extension.<br><br>This HDCP 2.2 compliant transmitter meets the HDMI specification, including 3D, Deep Color, and 4Kx2K video quality. The Auto Switch Mode allows the VE3912T to automatically switch to a newly plugged-in source. With its built-in PoH (Power over HDBaseT) function, it can receive power from the HDBaseT output port on the connected device, eliminating the need for a power adapter. As a combination of extension and switch for both digital and analog inputs, VE3912T is recommended to be deployed in settings with multiple source inputs, such as conference rooms, digital educational environment or wherever integration and simplification are required.<br><br><ul><li>Extends DisplayPort, HDMI or VGA signals up to 100 m over a single Cat 6/6a or ATEN 2L-2910 Cat 6 cable</li><li>PoH (Power over HDBaseT) – with its built-in PoH function, it receives power from the HDBaseT output port on the connected device</li><li>Perfect HDBaseT Compatibility – compatible with ATEN HDBaseT receivers, available to deliver crystal video and audio signals to Displayport/HDMI/VGA output port</li><li>Features RS-232 Serial Communication Switch – Command mode and Bypass mode to meet application requirements; users can command input port switch through RS-232 of receiver, such as VE2812R</li><li>EDID Expert™ – selects optimum EDID settings for high-quality display and use HDBaseT output as priority of optimum video resolution</li><li>Plug-and-play with no software installation required</li><li>Rack-mountable</li><li>Built-in 8KV/15KV ESD protection</li><li>Supports multiple source inputs (DisplayPort/HDMI/VGA) – easily switching among sources via a pushbutton</li><li>Auto Switch Mode – allows the VE3912T to automatically switch to a newly plugged-in source</li><li>HDMI (3D, Deep Color, 4k); HDCP 2.2 compliant</li><li>Superior video quality:</li><li>• HDMI/Displayport: 4K at distance up to 100 m via a Cat 6a or ATEN 2L-2910 Cat 6 cable</li><li>• VGA: 1600 x 1200 and 1920 x 1200 up to 100 m via a Cat 6a or ATEN 2L-2910 Cat 6 cable</li><li>HDBaseT Long Reach Mode – up to 150 m via a single Cat 5e/6 cable at resolutions up to 1080p</li><li>Mirrored Video Output – supports 4K@30Hz, 4:4:4 over the HDBaseT output, and a local HDMI output</li></ul>
ATHENS VE3912T. Type : Transmetteur AV, Résolution maximale : 4096 x 2160 pixels, Distance de transfert maximale : 100 m. Connectivité : Filaire, Entrée vidéo : 1 HDMI type A femelle (noir), 1 HDB-15 (VGA) femelle (bleu), 1 DisplayPort femelle (noir), Sortie vidéo : 1 HDMI type A femelle (noir). Consommation électrique (max.) : 8,77 W. Largeur : 147 mm, Profondeur : 173 mm, Hauteur : 30 mm.
