UbiQuiti PowerBeam M5 PBE-5AC-500 Wireless Bridge

<a href="https://www.ubnt.com/airmax/powerbeam-ac/" style="display: block;">https://www.ubnt.com/airmax/powerbeam-ac/</a><br><br>Incorporating a dish reflector design with proprietary airMAX® ac technology, the PowerBeam™ ac is ideal for CPE deployments requiring maximum performance.<br><br><b>Integrated Radio Design</b><br>Ubiquiti’s InnerFeed® technology integrates the radio into the feedhorn of an antenna, so there is no need for cables to connect the radio to the antenna. This improves performance because it eliminates cable losses.<br><br><b>Performance Breakthrough</b><br>airMAX® ac products offer improved latency, noise immunity, scalability and significantly increased throughput performance.<br><br><b>Superior Processing</b><br>Ubiquiti's airMAX® engine with custom IC dramatically improves TDMA latency and network scalability. The custom silicon provides hardware acceleration capabilities to the airMAX scheduler, to support the high data rates and dense modulation used in airMAX ac technology.<br><br><b>Incredible Antenna “Beam” Performance</b><br>The form factor of the PowerBeam™ ac features the highest gain for its size. The PowerBeam ac’s excellent beam directivity provides the best performance in high-noise environments.<br><br><b>Advanced Software Technology</b><br>Ubiquiti’s airMAX® technology is proven in millions of deployments worldwide, exhibiting outstanding performance in outdoor environments. The TDMA airMAX protocol enables unprecedented scalability, high throughput and low latency in unlicensed, multipoint networks.<br><br><b>Protective Radome</b><br>The PowerBeam™ ac PBE-5AC-500 includes a protective radome to shield the radio from nature's harshest elements.<br><br>

Ubiquiti Networks PBE-5AC-500. Antenna gain level (max): 27 dBi, Frequency band: 5 GHz, Processor model: Atheros MIPS 74Kc. Antenna type: Directional antenna, Polarization: Dual polarization, Voltage Standing Wave Ratio (VSWR): 1.5:1. Power consumption (max): 8.5 W. Width: 525 mm, Depth: 315 mm, Height: 525 mm. Dimensions (WxDxH): 620 x 620 x 386 mm

General

Antenna gain level (max)

27 dBi

Frequency band

5 GHz

Processor model

Atheros MIPS 74Kc

Antenna type

Directional antenna

Polarization

Dual polarization

Voltage Standing Wave Ratio (VSWR)

1.5:1

Power consumption (max)

8.5 W

Width

525 mm

Depth

315 mm

Height

525 mm

Dimensions (WxDxH)

620 x 620 x 386 mm
