<a href="https://teltonika-networks.com/product/tsw100/#features" style="display: block;">https://teltonika-networks.com/product/tsw100/#features</a><br><br>TSW100 – 5-port, unmanaged full Gigabit Ethernet switch supporting Power-over-Ethernet (802.3af and 802.3at standards). This device is classified as power source equipment (PSE), and when used in this way, TSW100 switch enables centralization of the power supply, providing up to 30 watts of power per port and reducing the effort for installing power. It has 10/100/1000 Mbps Ethernet ports to provide an economical high-bandwidth solution for your industrial Ethernet network.<br><br>
TSW100 - Unmanaged - Gigabit Ethernet (10/100/1000) - Power over Ethernet (PoE)
| Estimate Gross Weight | 0.77 |
|---|
|
|
||||
| Teltonika TSW100 - Unmanaged - Gigabit Ethernet (10/100/1000) - Power over Ethernet (PoE) | ||||
| 5 x LAN port - 10/100/1000 Mbps - IEEE 802.3 - IEEE 802.3u - 802.3az - PoE ports 1- 4 - 2 W/9 W/129 W | ||||
| Group | Network Equipment | |||
| Manufacturer | Teltonika | |||
| Manufacturer item no. | TSW100000000 | |||
| EAN/UPC | 4779027312828 | |||
| Description | ||||
| Teltonika Switch TSW100 5 Port Gigabit Industrial unmanaged POE Switch, , , , , ,Teltonika TSW100 5-Port Switch Overview TSW100 is the first industrial unmanaged switch from Teltonika Networks. Equipped with five Gigabit Ethernet ports, four of which are the IEEE802.3af and IEEE802.3at standards Support Power over Ethernet (PoE). Classified as Power Source Equipment (PSE), allows the centralization of power supply, delivers up to 30 watts per port and reduces the effort for the electricity installation. It has 10/100/1000 Mbps Ethernet ports for an economical solution with high bandwidth. Ideal for professional applications with high bandwidth, that offer both: reliable data connection and power supply. , ,Characteristics PoE - 4 x PoE ports with 802.3af and 802.3at support Power Budget - total power budget at PSE up to 120W Durability - rugged aluminum body Fastening - options for DIN rails and surface mount Ethernet - 5 x Gigabit Ethernet speeds of up to 1000Mbps Plug-N-Play - No additional configuration required scope of delivery TSW100 65W Euro PSU |
||||
| Extended details | ||||
| General | ||||
| Type | Switch | |||
| Other product features (i.e. waterproof, volume control, ...) | Unmanaged | |||
| Interfaces / Connectivity | ||||
| Amount of ports | Amount of ports: | |||
| Network | ||||
| Network standards | Ethernet; Power over Ethernet | |||
| Network ports | RJ-45 | |||
| Technical specifications | ||||
| Transmission rate | 1 Gbps | |||
| Additional nework or telephone functions | MDI Port Detection | |||
| Rack height units | 3 U | |||
| Measurements / weight | ||||
| Measurements | 115 x 32 x 95 mm | |||
|
|
||||
