Kingston 16GB 3200MT/s DDR4 ECC CL22 DIMM 1Rx8 Micron F

<a href="https://www.kingston.com/en/memory/search?partid=KSM32ES8%2F16MF" style="display: block;">https://www.kingston.com/en/memory/search?partid=KSM32ES8%2F16MF</a><br><br>Kingston's KSM32ES8/16MF is a 2G x 72-bit (16GB) DDR4-3200 CL22 SDRAM (Synchronous DRAM), 1Rx8, ECC, memory module, based on nine 2G x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-3200 timing of 22-22-22 at 1.2V. Each 288-pin DIMM uses gold contact fingers.<br><br><ul><li>Nominal and dynamic on-die termination (ODT) for data, strobe, and mask signals</li><li>Fly-by topology</li><li>Terminated control command and address bus</li><li>Low-power auto self refresh (LPASR)</li><li>Data bus inversion (DBI) for data bus</li><li>On-die VREFDQ generation and calibration</li><li>Single-rank</li><li>On-board I2 serial presence-detect (SPD) EEPROM</li><li>Temperature sensor with integrated SPD</li><li>16 internal banks; 4 groups of 4 banks each</li><li>Selectable BC4 or BL8 on-the-fly (OTF)</li></ul>
